Introduction to Fertilizer Disc Granulator
With arc structure & sturdy materials, disc granulator also called as disc pan granulator amkes the granulation rate upto 93% or more. Using direct line gearbox drive with VFD control the RPM rate can precisely be controlled to achieve desired results. There is no need of heavy foundation as the vibration levels are minimum. Disc pan granulator manufactured by us has sturdy structure & long life span.


  • Post


      Disc Pan Granulation Process

    The granulation process of disc granulation starts with mixture of fine fertilizer powder & binder is poured into pan & the disc starts rotating. Small amount of water is sprayed into pan as per requirement. With the rotation of the pan granules are formed. The size of the granules can be controlled by controlling RPM & the amount of water being sprayed into rotating pan.

    Model Inner Diam (mm) Side Height (mm) Rotation Speed (r/min) Motor Speed (kw) Capacity
    PDG-1 1800 300 18 3 0.3-0.5(t/h)
    PDG-2 2000 350 16 5.5 0.5-1(t/h)
    PDG-3 2500 380 13.5 7.5 1-2(t/h)
    PDG-4 2800 400 13 11 2-3(t/h)
    PDG-5 3000 420 12.5 15 3-4(t/h)
